Product Description
| Spare parts for 12V190 |
| No. | Part Name | Part Number | Qty |
| 1 | CYLINDER BLOCK ASSEMBLY | | 1 |
| | | | 1 |
| 3 | CYLINDER HEAD ASSEMBLY | 127.03.00 | 12 |
| 4 | OIL SUMP ASSEMBLY | 12VB.04.00B | 1 |
| 5 | PISTON AND CONNECTING ROD ASSEMBLY | 127.05.00 | 12 |
| 6 | CAMSHAFT AND GEAR TRAIN ASSEMBLY | 127.06.00 | 1 |
| 7 | TORSIONAL VIBRATION DAMPER ASSEMBLY | 12VB.07.00 | 1 |
| 8 | INTAKE LINE ASSEMBLY | 127.08.00B | 1 |
| 9 | EXHAUST LINE ASSEMBLY | 127.09.00A | 1 |
| 11 | NATURAL GAS PIPELINE | 127.14.00 | 1 |
| 12 | MEGNETO TRANSMISSION ASSEMBLY | 127.15.00 | 1 |
| 13 | OIL PUMP ASSEMBLY | 12V.17.00C | 1 |
| 14 | OIL FILTER ASSEMBLY | 12VB.18.00B | 1 |
| 15 | CENTRIFUGAL FILTER ASSEMBLY | 12VB.19.00 | 1 |
| 16 | LUBRICATING PIPING | 127.20.00 | 1 |
| 17 | OIL COOLER ASSEMBLY | 12VB.21.00 | 1 |
| 18 | WATER PUMP ASSEMBLY | 12VB.22.00B | 2 |
| 19 | Cooling line system | 127.24.00 | 1 |
| 20 | INTER-COOLER ASSEMBLY | 12V.27.00 | 1 |
| 21 | HAND PRIMING OIL PUMP ASSEMBLY | 12V.29.00 | 1 |
| 25 | OVERSPEED SAFETY DEVICE | 12VB.37J2.00 | 1 |
| 26 | SPECIAL TOOLS | 127.42.00 | 3 |
| 27 | COUPLING ASSEMBLY | 163.44.00 | 1 |
| 29 | ELECTRIC STARTING SYSTEM | 127.46D.00 | 1 |
| 30 | OIL PUMP BRACKET ASSEMBLY | 12VB.48.00 | 1 |
| 31 | CARBURETTER ASSEMBLY | 127.86.00 | 2 |
| 32 | NATURAL GAS PRESSURE REGALATING VALVE | 127.87.00 | 1 |
| 33 | GOVERNOR CONNECTION ASSEMBLY | 127.89.00 | 1 |
| 35 | Electromagnetic valve | 127.91.00 | 1 |
| 36 | TURBOCHARGER ASSEMBLY | 127.20GJ.00EB | 2 |
Some parts
Product Model Name Product Name
12VB.01.04B Cylinder head bolts
12VB.01.07A Cylinder head nuts
12VB.01.131 Cylinder head bolt washers
12VB.01.141 Throttle valve
12VB.01.03 Cylinder head gasket 1.5 mm (copper)
12VB.01.05 Bushing
12VB.03.10 Rocker arm seat assembly (forged steel)
12VB.03.10 Rocker seat assembly (cast iron)
12VB.03.10.01 Intake rocker arm assembly (forged steel)
12VB.03.10.01 Intake rocker arm assembly (cast iron)
12VB.03.10.03 Exhaust rocker arm assembly (forged steel)
12VB.03.10.03 Exhaust rocker arm assembly (cast iron)
12VB.03.50.01 Rocker arm boss
12VB.03.10.02 Rocker arm bushings
12VB.03.10.04 Rocker arm shaft
12VB.03.10.05A Rocker arm holder
12VB.03.25 Oil injector bushing (seamless steel tube, zinc plated)
12VB.03.25 Oiler sheath (stainless steel)
12VB.03.25 Oiler sheath (brass)
127.03.80.02B Oiler sheath (gas engine)
601.03.80.02B Oiler sheath (3000 type)
12VB.03.03C Rocker cross-bridge (new type, without toggle)
12VB.03.03B Rocker arm cross-axle (old type, square port, forged steel)
12VB.03.03B Rocker arm cross-bridge (old type, square port, cast iron)
12VB.03.03B Rocker arm cross-bridge (old style, round port, forged steel)
12VB.03.60B Rocker arm adjusting screw (new style)
12VB.03.60 Rocker arm adjusting screw (old style)
12VB.03.90B Cross-bridge adjusting screw (new style)
12VB.03.60A Cross-bridge adjusting screw (old style)
12VB.03.30B Cross-bridge boss (new style)
12VB.03.30 Cross-bridge boss (old style)
M14X1 Cross-bridge adjusting screw nut (high strength)
12VB.03.15A Spring-loaded upper seat (new style)
12VB.03.15 Spring-loaded upper seat (old style)
Detailed Photos
Company Profile
JiNan GuoHua Green Power Equipment Co.Ltd, is professional production in diesel generator sets, gas generator sets and parts for nearly 12 years, covering production, sales and maintenance, having CE,ISO general notary certificate,etc. At present, we have formed a perfect sales and maintenance sreveice system. And have set up two workingroom, covering an area of more than 5,000 square meters. The company has strong technical force, excellent equipment. We would like to serve the customers around the world with our quality first products, reasonable price.
Our main business:
Early period: consulting, design, supply and installation of engine power generation equipment, including diesel power generation, natural gas power generation, coal gas power generation, biogas power generation and parts.
Mid-period: supply Jinan diesel engine (Jichai/Chidong brand) accessories. GUOHUA has two warehouses. One is located in ShanDong province and mainly supplies the domestic North, South markets and foreign. The other is located in XinJiang province and mainly supplies the western market, which allows fast delivery and quality assurance.
Later period: The company also provides engine overhaul and maintenance services with experienced engineers and professional skills. Traces of JNGH can be seen not only in China, but also in Ghana, Kazakhstan, Vietnam and Myanmar. Provide overhaul and maintenance services later.
Our Advantages
